2021-10-16 18:45:08   2078

White USB magnetic 4 pin TPE cable connector, Magnetic tensile force about 650g, stably working,Pogo pin and stainless steel fixed column structure

  • Trademark : HytePro®
  • Part Number : HTP-CA-M511
  • Mounting Type : Through Hole
  • Private Mold : Yes
  • Number of Pins : 4
  • Magnet Material : NdFeB
  • Magnetic Force : ≥ 600gf
  • Length : 1.0 Meter
  • Jacket : TPE,PVC
  • Interface : USB A Male
  • Color : White
  • Cable Type : Round
  • Conductor : Tinned Copper
  • Wire Gauge : 22AWG,28AWG
  • Function : Charging and data transfer
  • Insert Material : PA66+30% GF
  • Voltage Rating : 5~24 VDC
  • Current Rating : 3 Amps
  • Fastening Type : Magnetic
  • Operating Temperature : -40°C ~ 85°C
  • RoHS : Compliant
  • Customizable : Yes
  • Package : Poly bag,Carton box
  • Usage : Industrial Automation,Aerospace,Drones and Robots,Medicine and Healthcare,Consumer Electronics
X
Samples Request? Get quotation list?
We will reply to you within 30 minutes
Product Name:USB magnetic 4 pin cable connector M511

Product Name: USB magnetic 4 pin cable connector M511

Part Number: HTP-CA-M511

- Magnetic tensile force about 650g, stably working;

- Pogo pin and stainless steel fixed column structure;

- PC with PA66+30%GF Plastic body design and support 5~24V/3A;

- For data Sync and charging with anti-misplugging design;

- The contact pins is 5μ gold plated and magnets is nickel-plated;

- The male connect with usb cable,desing magnets pole for anti-reverse, easy to use;

HytePro magnetic connectors are more convenient, requiring no precise alignment, the male and female part will be automatically connected by magnetic adsorption, effectively prevent mis-plugging.

HytePro fast charging magnetic cable features a pair of male and female magnetic connector that helps guide the plug to the power and data port of your devices.

The pogo pin contacts are gold plated, NdFeB magnet nickel plated, can load more higher currents, keep more stable connection,  to achieve fast charging and data transfer capabilities.

HytePro magnetic connection is strong enough to resist most unintended disconnects, ensure more stable electrical connectivity, but if someone trips on the cable, it will disconnect to stay safe of your devices.

HytePro magnetic connectors are widely application, such as industrial automation, aerospace, drones and robots, medicine and healthcare, sports bracelet, GPS tracker, smart watch, beauty instrument and etc.

HytePro magnetic charging cable upgrade to TPE jacket and TPE over moulding, become more soft and comfortable, delicate touch, high elasticity, bring an amazing experience, greatly improve the feel and more durable.

USB magnetic 4 pin cable connector M511USB magnetic 4 pin cable connector M511USB magnetic 4 pin cable connector M511USB magnetic 4 pin cable connector M511USB magnetic 4 pin cable connector M511USB magnetic 4 pin cable connector M511USB magnetic 4 pin cable connector M511USB magnetic 4 pin cable connector M511
