HytePro powerful 2 pogo pin circular magnetic power connector, magnetic force is up to 1200gf, 5-24V/1-8A high current

  • Trademark : HytePro®
  • Part Number : HTP-CON-M416
  • Mounting Type : Through Hole
  • Private Mold : Yes
  • Number of Pins : 2
  • Magnetic Force : ≥1000gf
  • Voltage Rating : 5~24 VDC
  • Current Rating : 6A
  • Plastic Housing : PA66+30% GF
  • Magnet : NdFeB
  • Spring : Stainless steel SUS304/SWP
  • Needle : Brass C2700 / C3604
  • Insulation Resistance : 100MΩ at 100VDC
  • Gold Plated : 3~30μ
  • Operating Temperature : -40°C ~ 85°C
  • Contact Impedance : Dynamics≤30MΩ
  • RoHS : Compliant
  • Customizable : Yes
  • Package : Tube,Carton box
  • Usage : Industrial Automation,Aerospace,Drones and Robots,Medicine and Healthcare,Consumer Electronics
X
Samples Request? Get quotation list?
We will reply to you within 30 minutes
Product Name:HytePro powerful 2 pogo pin magnetic circular connector M416

Product Name: HytePro powerful 2 pogo pin magnetic circular connector M416

Part Number: HTP-CON-M416

- Magnetic tensile force about 1200g;

- DC power charging with 5-24V/1-6A and anti-reverse design;

- Widely used in wearable devices, storage devices, electronic devices,etc;

- 2pin magnetic connector with anti-reverse design, automatic connection method, easy to use;

- Spring pin design and HTN plastic body structure, round magnet design, let you get a better experience.

HytePro magnetic connectors are more convenient, requiring no precise alignment, the male and female part will be automatically connected by magnetic adsorption, effectively prevent mis-plugging.

HytePro fast charging magnetic cable features a pair of male and female magnetic connector that helps guide the plug to the power and data port of your devices.

The pogo pin contacts are gold plated, NdFeB magnet nickel plated, can load more higher currents, keep more stable connection,  to achieve fast charging and data transfer capabilities.

HytePro magnetic connection is strong enough to resist most unintended disconnects, ensure more stable electrical connectivity, but if someone trips on the cable, it will disconnect to stay safe of your devices.

HytePro magnetic connectors are widely application, such as industrial automation, aerospace, drones and robots, medicine and healthcare, sports bracelet, GPS tracker, smart watch, beauty instrument and etc.

Powerful 2 pogo pin magnetic circular connector M416Powerful 2 pogo pin magnetic circular connector M416Powerful 2 pogo pin magnetic circular connector M416Powerful 2 pogo pin magnetic circular connector M416Powerful 2 pogo pin magnetic circular connector M416Powerful 2 pogo pin magnetic circular connector M416

Self mating mount


HytePro self-mating mount magnetic connector attracted by the magnetic force and actually slides into the socket automatically when the plug approaches the socket. This makes it efficient and comfortable to handle and ensure proper connection.


Auto break-away function


The auto break-away function is designed to disconnect when the plug or cable is subjected to a sharp pull (intentional or unintentional). This avoids the risk of injury to the user and damage to the connector. Deliberate removal of the plug is quick and easy due to the disconnect function.


Stable, fast, reliable, simple


HytePro magnetic self-matching connectors automatically detect connections and prevent tearing. They are ideal for connections that require more frequent connections and disconnections.


Powerful Magnetic Connector


HytePro has developed the powerful magnetic connector that offers an intelligent alternative to mechanical mating. HytePro self-mating magnetic connector provides all common functions and is suitable for power and data sync.
