2021-10-15 07:06:41   3011

End with straight solder pin, for data Sync and charging with anti misplug design, stably working, The contact pins is 5μ gold plated

  • Trademark : HytePro®
  • Part Number : HTP-CON-M425S
  • Mounting Type : Through Hole
  • Private Mold : Yes
  • Number of Pins : 5
  • Magnetic Force : ≥600gf
  • Voltage Rating : 5~24 VDC
  • Current Rating : 3A
  • Plastic Housing : PA66+30% GF
  • Magnet : NdFeB
  • Spring : Stainless steel SUS304/SWP
  • Needle : Brass C2700 / C3604
  • Insulation Resistance : 100MΩ at 100VDC
  • Gold Plated : 3~30μ
  • Operating Temperature : -40°C ~ 85°C
  • Contact Impedance : Dynamics≤30MΩ
  • RoHS : Compliant
  • Customizable : Yes
  • Package : Tube,Carton box
  • Usage : Industrial Automation,Aerospace,Drones and Robots,Medicine and Healthcare,Consumer Electronics
X
Samples Request? Get quotation list?
We will reply to you within 30 minutes
Product Name:Solder 5 pin magnetic electrical connectors M425S

Product Name: Solder 5 pin magnetic electrical connectors M425S

Part Number: HTP-CON-M425S

- Pin type: End with straight solder pin;

- For data Sync and charging with anti misplug design;

- Magnetic tensile force about 600g, stably working;

- The contact pins is 5μ gold plated and magnets is nickel-plated;

- Solder pin and stainless steel fixed column structure;

- PA66+30%GF Plastic body design and support 5~24V/3A;

- Widely used in Mobile, Communications, Chargers,Sports bracelet,GPS tracker,Smart watch,Beauty instrument,Medical device,Unmanned aerial vehicle and etc.

- HytePro majors in magnetic usb cable for about 11 years,supports OEM&ODM,we could custom make every details you want.

Solder 5 pin magnetic electrical connectors M425SSolder 5 pin magnetic electrical connectors M425SSolder 5 pin magnetic electrical connectors M425SSolder 5 pin magnetic electrical connectors M425SSolder 5 pin magnetic electrical connectors M425S
